Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 4 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 4 | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:15.00 NOMINAL | (A) OUTER DIAMETER, TOP:9.53 IN (242.06 MM) | HANDLE:NONE | |
BETA RATING:N/A | (B) OUTER DIAMETER, BOTTOM:9.53 IN (242.06 MM) | Seal Material:BUNA-N | |
COLLAPSE PRESSURE RATING:NOT RATED | (C) INNER DIAMETER, TOP:5.18 IN (131.57 MM) | Type of Adhesive：PLASTISOL | |
MAXIMUM TEMPERATURE:225 F | (D) INNER DIAMETER,BOTTOM:0.44 IN (11.18 MM) | TYPE OF ENDCAP:PLATED STEEL | |
DIRECTION OF FLOW:OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:20 PSID | (E) LENGTH:19.50 IN (11.18 MM) (F) THREAD:NONE | CENTER TUBE：PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:PAPER | ||
FILTER AREA:SQ.IN. | |||
PLATING: NONE | |||
OUTER JACKET:YES - METAL | |||
CONFIGURATION:SINGLE OPEN END/BH | |||
