Product Details:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Glassfiber | Condition: | New |
| Power: | 800 | Weight: | 0.7 Kg |
| Dimension(L*W*H): | OEM | Warranty: | 1 Year |
| Weight [kg]: | 0.7 | Area Of Application: | Hydraulics |
| Filter Fineness [um]: | B4.5=1000 | Max.differential Pressure [bar]: | 10 |
| Filter Medium: | Glass Fiber | Seals - Material: | NBR |
| Permitted Continuous Use Temperature: | -25°C To +120°C | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 3.00ABSOLUTE | (A) Outer Diameter, Top:5.92IN | Handle: YES | |
Beta Rating: B3=200 | (B) Outer Diameter, Bottom:5.92IN | Seal Material: VITON | |
Collapse Pressure Rating: 150 PSI | (C) Inner Diameter, Top:3.79IN | Type of Adhesive: EPOXY | |
Maximum Temperature:275F | (D) Inner Diameter, Bottom:3.79IN | Type of Endcap:SYNTHETIC | |
Direction of Flow: OUTSIDE->IN | (E) Length:**IN | Center Tube:NONE | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area:SQ.IN. | |||
Plating:NONE | |||
Outer Jacket: NONE - NONE | |||
Configuration: DOUBLE OPEN END | |||
