Product Details:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Condition: | New |
| Power: | 800 | Weight: | 0.72 Kg |
| Dimension(L*W*H): | OEM | Warranty: | 1 Year |
| Weight [kg]: | 0.72 | Seals - Material: | NBR |
| Filter Medium: | Glass Fiber | Area Of Application: | Hydraulics |
| Flow Direction: | Outside To Inside | Max.differential Pressure [bar]: | 20 |
| Filter Fineness [um(c)]: | B10=200 / B12=1000 | Permitted Continuous Use Temperature: | -30°C To +100°C |
| Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 10.00 ABSOLUTE | (A) Outer Diameter, Top:3.10IN | Handle: NONE | |
Beta Rating: B10=200 | (B) Outer Diameter, Bottom:3.10IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: 450 PSI | (C) Inner Diameter, Top: 0.61IN | Type of Adhesive: EPOXY | |
Maximum Temperature: 250 F | (D) Inner Diameter, Bottom: | Type of Endcap:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 9.40IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: N/A | |||
Plating: N/A | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
