Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1.2 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 1.2 | Area Of Application: | Hydraulics |
| Max. Will. Differential Pressure [bar]: | 10 | Filter Medium: | Cellulose |
| Seals-Material: | NBR | Filter Fineness [um(c)]: | B10=2 |
| Permitted Continuous Use Temperature: | -25°C To +120°C | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:10.00ABSOLUTE | (A) Outer Diameter, Top:4.17 IN (105.92 MM) | Handle:NONE | |
Beta Rating: B10=2 | (B) Outer Diameter, Bottom:4.17 IN (105.92 MM) | Seal Material: BUNA-N | |
Collapse Pressure Rating:145PSI | (C) Inner Diameter, Top:0.41IN (10.41 MM) | Type of Adhesive: N/A | |
Maximum Temperature:212F | (D) Inner Diameter, Bottom:0.41 IN (10.41 MM) | Type of Endcap:STEEL | |
Direction of Flow: INSIDE->OUT RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:20 PSID | (E) Length:18.31 IN (0.00 MM) (F) THREAD:NONE | Center Tube: STEEL | |
Get the quote by contacting us | Type of Media:PAPER | ||
Filter Area: 1460SQ.IN. | |||
Plating:N/A | |||
Outer Jacket:YES | |||
Configuration:SINGLE OPEN END | |||
