Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 1 | Field Of Application: | Oil Filtration |
| Max. Will. Differential Pressure [bar]: | 210 | Filter Medium: | Glass Fibre |
| Filter Fineness [μm(c)]: | B12=1000 | Seals-Material: | NBR |
| Zul. Continuous Operating Temperature: | -25°C To +120°C | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:10.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:1.75 IN (44.45 MM) | HANDLE:NONE | |
BETA RATING:1000/12.4 | (B) OUTER DIAMETER, BOTTOM:1.75 IN (44.45 MM) | Seal Material:VITON | |
COLLAPSE PRESSURE RATING:3045 PSID | (C) INNER DIAMETER, TOP:0.87 IN (22.10 MM) | Type of Adhesive: | |
MAXIMUM TEMPERATURE:248 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:PLATED STEEL | |
DIRECTION OF FLOW:OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:20 PSID | (E) LENGTH:6.85 IN (0.00 MM) (F) THREAD:NONE | CENTER TUBE: STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:150 SQ.IN. | |||
PLATING: | |||
OUTER JACKET:NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
