Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 1 | Application: | Hydraulics |
| Inner Diameter [mm]: | 22.6 | Filter Medium: | Synthetic |
| Height [mm]: | 145.5 | Filter Fineness [μm(c)]: | B12=1000 |
| Outer Diameter [mm]: | 47.6 | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:12.00 ABSOLUTE | (A) Outer Diameter, Top:1.87 IN (47.50 MM) | Handle:YES | |
Beta Rating:B12 = 4000 | (B) Outer Diameter, Bottom:1.87 IN (47.50 MM) | Seal Material: VITON | |
Collapse Pressure Rating:450 PSID | (C) Inner Diameter, Top:0.82 IN (20.83 MM) | Type of Adhesive: EPOXY | |
Maximum Temperature:400 F | (D) Inner Diameter, Bottom:1.08 IN (27.43 MM) | Type of Endcap:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:50 PSID | (E) Length:6.00 IN (0.00 MM) (F) THREAD:NONE | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area: 1.25 SQ.FT. | |||
Plating:ZINC PLATED | |||
Outer Jacket:NONE - NONE | |||
Configuration:SINGLE OPEN END | |||
