Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 1 | Application: | Hydraulics |
| Seals-Material: | NBR | Filter Fineness [μm(c)]: | B10=200 |
| Max. Will. Differential Pressure [bar]: | 21 | Zul. Continuous Operating Temperature: | -25°C To +120°C |
| Filter Medium: | Glass Fibre | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:10.00 | (A) Outer Diameter, Top:1.77 IN (44.96 MM) | Handle:NONE | |
Beta Rating:200 | (B) Outer Diameter, Bottom:1.77 IN (44.96 MM) | Seal Material: | |
Collapse Pressure Rating:3046 PSID | (C) Inner Diameter, Top:1.00 IN (25.40 MM) | Type of Adhesive: EPOXY | |
Maximum Temperature:212 F | (D) Inner Diameter, Bottom: | Type of Endcap:STEEL | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:20 PSID | (E) Length:4.49 IN (0.00 MM) (F) THREAD:NONE | Center Tube:STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area:84.67 SQ.IN. | |||
Plating:N/A | |||
Outer Jacket:NONE | |||
Configuration: | |||
