Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 1 | Application: | Hydraulics |
| Seals-Material: | NBR | Filter Medium: | Glass Fibre |
| Filter Fineness [μm(c)]: | B12=1000 | Max. Will. Differential Pressure [bar]: | 30 |
| Zul. Continuous Operating Temperature: | -25°C To +120°C | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:10.00 ABSOLUTE | (A) Outer Diameter, Top:2.36 IN (59.94 MM) | Handle:NONE | |
Beta Rating:BX=200 | (B) Outer Diameter, Bottom:2.36 IN (59.94 MM) | Seal Material:BUNA-N | |
Collapse Pressure Rating:450 PSID | (C) Inner Diameter, Top:1.35 IN (34.29 MM) | Type of Adhesive: N/A | |
Maximum Temperature:225 F | (D) Inner Diameter, Bottom: | Type of Endcap:CORROSION RESISTANT STEEL | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:50 PSID | (E) Length:9.00 IN (0.00 MM) (F) THREAD:NONE | CENTER TUBE:CORROSION RESISTANT STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area: SQ.IN. | |||
Plating:ZINC PLATED | |||
Outer Jacket:NONE - NONE | |||
Configuration: | |||
