Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 1 | Application: | Hydraulics |
| Filter Medium: | Glass Fibre | Filter Fineness [μm(c)]: | 10 |
| Outer Diameter [mm]: | 55.5 | Height [mm]: | 169 |
| Inner Diameter [mm]: | 28 | Zul. Continuous Operating Temperature: | -30°C To 100°C |
| Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:10.00 ABSOLUTE | (A) Outer Diameter, Top:2.17 IN (55.12 MM) | Handle:NONE | |
Beta Rating:B10=200 | (B) Outer Diameter, Bottom:2.17 IN (55.12 MM) | Seal Material:BUNA-N | |
Collapse Pressure Rating:450 PSID | (C) Inner Diameter, Top:1.12 IN (28.45 MM) | Type of Adhesive:EPOXY | |
Maximum Temperature:225 F MAX | (D) Inner Diameter, Bottom: | Type of Endcap:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:0 PSID | (E) Length:6.66 IN (0.00 MM) (F) THREAD:NONE | CENTER TUBE: | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area: SQ. IN." | |||
Plating:PLATED STEEL | |||
Outer Jacket:NONE | |||
Configuration:SINGLE OPEN END | |||
