Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 0.74 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 0.74 | Area Of Application: | Hydraulics |
| Seals - Material: | NBR | Max.differential Pressure [bar]: | 30 |
| Mesh Size [um]: | 25 | Perm. Continuous Use Temperature: | -25°C To +120°C |
| Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:25.00 | (A) OUTER DIAMETER, TOP:3.63IN | Handle: NONE | |
BETA RATING: | (B) OUTER DIAMETER, BOTTOM：3.63IN | Seal Material:BUNA-N | |
COLLAPSE PRESSURE RATING: | (C) INNER DIAMETER, TOP:1.89IN | Type of Adhesive： | |
MAXIMUM TEMPERATURE: | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) LENGTH:6.36IN | CENTER TUBE:STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:304 SS WIRE | ||
FILTER AREA:SQ.IN. | |||
PLATING:ZINC PLATED | |||
OUTER JACKET:NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
