Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 7.5 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 7.5 | Area Of Application: | Hydraulics |
| Flow Direction: | Outside To Inside | Filter Medium: | Glass Fibre |
| Max. Will. Differential Pressure [bar]: | 20 | Bypass Valve Opening Pressure [bar]: | 3 |
| Seals-Material: | NBR | Filter Fineness [μm(c]: | B10=200, B12=1000 |
| Zul. Continuous Operating Temperature: | -30°C To +100°C | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:10.00 ABSOLUTE | (A) OUTER DIAMETER, TOPl:5.63 IN (143.00 MM) | Handle: YES | |
BETA RATING:B12 = 200 | (B) OUTER DIAMETER, BOTTOM:5.63 IN (143.00 MM) | Seal Material:VITON | |
COLLAPSE PRESSURE RATING::150 PSID | (C) INNER DIAMETER, TOP:3.34 IN (84.84 MM) | TYPE OF ADHESIVE:EPOXY | |
MAXIMUM TEMPERATURE:300 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) LENGTH:36.00 IN (0.00 MM) | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:SQ.IN. | |||
PLATING:ZINC PLATED | |||
OUTER JACKET:NONE - NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
