Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 1 | Area Of Application: | Hydraulics |
| Max. Will. Differential Pressure [bar]: | 21 | Filter Medium: | Wire Mesh |
| Seals-Material: | NBR | Mesh Size [μm]: | 100 |
| Zul. Continuous Operating Temperature: | -25°C To +120°C | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:100.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:3.10 IN (78.74 MM) | Handle:NONE | |
BETA RATING: | (B) OUTER DIAMETER, BOTTOM:3.10 IN (78.74 MM) | Seal Material: | |
COLLAPSE PRESSURE RATING:450 PSID | (C) INNER DIAMETER, TOP:1.70 IN (43.18 MM) | TYPE OF ADHESIVE: | |
MAXIMUM TEMPERATURE:400 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:STEEL | |
Direction of Flow: OUTSIDE->IN | (E) LENGTH:9.84 IN (0.00 MM) | CENTER TUBE: STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:WIRE MESH | ||
FILTER AREA: | |||
PLATING: | |||
OUTER JACKET:NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
