Product Details:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Glassfiber | Condition: | New |
| Power: | 800 | Weight: | 1 Kg |
| Dimension(L*W*H): | OEM | Warranty: | 1 Year |
| Weight [kg]: | 0.5 | Seals - Material: | NBR |
| Area Of Application: | Hydraulics | Filter Medium: | Glass Fiber |
| Filter Fineness [um(c)]: | B7=1000 | Max.differential Pressure [bar]: | 10 |
| Perm. Continuous Use Temperature: | -25°C To +120°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 3-20ABSOLUTE | (A) Outer Diameter, Top: 3.17 IN | Handle: NONE | |
Beta Rating: B6=200 | (B) Outer Diameter, Bottom:3.17 IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: 150 PSI | (C) INNER DIAMETER, TOP:1.93 IN | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:13.00 IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: N/A | |||
Plating: ZINC PLATED | |||
Outer Jacket: NONE - NONE | |||
Configuration: SINGLE OPEN END | |||
