Product Details:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Glassfiber | Condition: | New |
| Power: | 800 | Weight: | 1 Kg |
| Dimension(L*W*H): | OEM | Warranty: | 1 Year |
| Weight [kg]: | 1 | Application: | Hydraulics |
| Filter Medium: | Synthetic | Filter Fineness [μm]: | B5=1000 |
| Height [mm]: | 203 | Bypass Valve Opening Pressure [bar: | 3 |
| Outer Diameter [mm]: | 73 | Inner Diameter [mm]: | 34 |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 10.00 ABSOLUTE | (A) Outer Diameter, Top: 2.75 IN (69.85 MM) | HANDLE:YES | |
Beta Rating: B12=200 | (B) Outer Diameter, Bottom:2.75 IN (69.85 MM) | Seal Material: VITON | |
Collapse Pressure Rating: 250 PSID | (C) INNER DIAMETER, TOP:1.34 IN (34.04 MM) | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:275 F | (D) Inner Diameter, Bottom:** | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:4.97 IN (0.00 MM) | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ.IN. | |||
PLATING: ZINC PLATED | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
