Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1.5 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 1.5 | Field Of Application: | Hydraulics |
| Seals-Material: | NBR | Flow Direction: | Outside To Inside |
| Filter Medium: | Wire Mesh | Mesh Size [μm]: | 74 |
| Zul. Continuous Operating Temperature: | -30°C To 100°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:74.00 | (A) OUTER DIAMETER, TOP:3.75 IN (95.25 MM) | HANDLE:NONE | |
BETA RATING:B74=200 | (B) OUTER DIAMETER, BOTTOM:3.75 IN (95.25 MM) | Seal Material:BUNA-N | |
COLLAPSE PRESSURE RATING:290 PSID | (C) INNER DIAMETER, TOP:2.23 IN (56.64 MM) | Type of Adhesive：EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:CORROSION RESISTANT STEEL | |
DIRECTION OF FLOW:OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:20 PSID | (E) LENGTH:13.00 IN (0.00 MM) (F) THREAD:NONE | CENTER TUBE:CORROSION RESISTANT STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:304 SS WIRE | ||
FILTER AREA:SQ.IN. | |||
PLATING:ZINC PLATED | |||
OUTER JACKET:NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
