Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 1 | Field Of Application: | Hydraulics |
| Seals - Material: | VITON | Filter Medium: | Glass Fiber |
| Max. Permissible Differential Pressure: | 210 | Filter Fineness [μm(c)]: | B12=1000 |
| Perm. Continuous Use Temperature: | -25°C To +120°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:10.00 | (A) OUTER DIAMETER, TOP:1.77 IN (44.96 MM) | HANDLE:NONE | |
BETA RATING:200 | (B) OUTER DIAMETER, BOTTOM:1.77 IN (44.96 MM) | Seal Material: | |
COLLAPSE PRESSURE RATING:3046 PSID | (C) INNER DIAMETER, TOP:1.00 IN (25.40 MM) | Type of Adhesive：EPOXY | |
MAXIMUM TEMPERATURE:212 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:STEEL | |
DIRECTION OF FLOW:OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:20 PSID | (E) LENGTH:4.49 IN (0.00 MM) (F) THREAD:NONE | CENTER TUBE:STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:84.67 SQ.IN. | |||
PLATING:N/A | |||
OUTER JACKET:NONE | |||
CONFIGURATION: | |||
