Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50

Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50

Large Image :  Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50

Product Details:
Place of Origin: Hebei, China
Brand Name: BAMA
Payment & Shipping Terms:
Minimum Order Quantity: 20 pieces
Price: $50.00/pieces 1-9 pieces
Packaging Details: we pack our goods in PP bags and brown cartons. If you have a legally registered patent, we can pack the goods into your brand box after receiving your authorization.
Supply Ability: 10000 Piece/Pieces per Month
Contact Now

Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50

Description
Condition: New Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C
Weight (KG): 1.75 Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2020 Warranty Of Core Components: 3 Month
Core Components: Glass Fiber Warranty: 1 Year
Weight [kg]:: 1,75 Seals-material:: NBR
Filter Fineness [μm(c)]:: < B4=200 / B5=1000 Area Of Application: Hydraulics
Flow Direction:: Outside To Inside Max. Will. Differential Pressure [bar]:: 20
Zul. Continuous Operating Temperature:: -25°C To +120°C Filter Medium:: Glass Fibre

Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 0
Products Description
Performance Data
Dimensional Specifications
Physical Specifications
MICRON RATING:6.00 ABSOLUTE
(A) OUTER DIAMETER, TOP:4.50 IN (114.30 MM)
HANDLE:NONE
BETA RATING:B6= 200
(B) OUTER DIAMETER, BOTTOM:4.50 IN (114.30 MM)
Seal Material:BUNA-N
COLLAPSE PRESSURE RATING:250 PSID
(C) INNER DIAMETER, TOP:2.56 IN (65.02 MM)
Type of Adhesive：EPOXY
MAXIMUM TEMPERATURE:225 F
(D) INNER DIAMETER,BOTTOM:
TYPE OF ENDCAP:CORROSION RESISTANT STEEL
DIRECTION OF FLOW:OUTSIDE->IN

RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:50 PSID
(E) LENGTH:13.09 IN (0.00 MM)
(F) THREAD:NONE
CENTER TUBE:CORROSION RESISTANT STEEL



Get the quote by contacting us
TYPE OF MEDIA:MICROGLASS
FILTER AREA:SQ.IN.
PLATING:ZINC PLATED
OUTER JACKET:NONE
CONFIGURATION:
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 1
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 2
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 3
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 4
Company Profile
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 5
Langfang BangMao Filter Equipment Co., Ltd.
Our trademark is: BAMA
Our main products: Interchange of hydraulic filters & filter elements Replacement, wire filter, coalescing separation filter, vacuum pump filter, air filter, oil filter, etc. With an efficient R & D team, mass production ability and a reliable QC system, Langfang Bangmao offers OEM & ODM service to help clients build their own reputations and become increasingly competitive.
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 6
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 7
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 8
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 9
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 10
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 11
Why Choose Us
· Professional manufacturer with many years' experience
· Good quality with competitive price
· OEM & ODM are welcome
· Produce according to your sample or drawing
· Various payment items are acceptable
· Good service by experienced manager
· Each product is individually under strict inspection
· On-time delivery
· Small MOQ is acceptable
Our Team
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 12
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 13
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 14
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 15
Foreign trade clerk: 15 people
Product R&D personnel: 10 people
After-sales personnel: 10 people
Production staff: 30 people
Exhibition
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 16
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 17
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 18
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 19
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 20
Outside to Inside Flow Direction Hydraulic Oil Return Filter Element HC2286FKP12H50 21
