Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 8 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 8 | Area Of Application: | Hydraulics |
| Flow Direction:: | Outside To Inside | Max. Will. Differential Pressure [bar]:: | 20 |
| Filter Medium:: | Glass Fibre | Filter Fineness [μm(c)]:: | B10=200 / B12=1000 |
| Seals-material:: | NBR | Zul. Continuous Operating Temperature:: | -30°C To+100°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:50.00 | (A) OUTER DIAMETER, TOP:5.65 IN (143.51 MM) | HANDLE:NONE | |
BETA RATING: | (B) OUTER DIAMETER, BOTTOM：5.65 IN (143.51 MM) | Seal Material:BUNA-N | |
COLLAPSE PRESSURE RATING:300 PSID | (C) INNER DIAMETER, TOP: | Type of Adhesive：EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) INNER DIAMETER,BOTTOM:3.75 IN (95.25 MM) | TYPE OF ENDCAP:PLATED STEEL | |
DIRECTION OF FLOW:OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:20 PSID | (E) LENGTH:36.26 IN (95.25 MM) (F) THREAD: | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:304 SS WIRE | ||
FILTER AREA:SQ.IN. | |||
PLATING: | |||
OUTER JACKET:NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
