Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 2 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 2 | Field Of Application: | Hydraulics |
| Max. Will. Differential Pressure [bar]: | 10 | Filter Medium: | Glass Fibre |
| Filter Fineness [μm(c)]: | B12=1000 | Zul. Continuous Operating Temperature: | -25°C To +120°C |
| Seals-material: | NBR |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:10.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:3.90 IN (99.06 MM) | HANDLE:NONE | |
BETA RATING:B10=200 | (B) OUTER DIAMETER, BOTTOM:3.90 IN (99.06 MM) | Seal Material:BUAN-N | |
COLLAPSE PRESSURE RATING: | (C) INNER DIAMETER, TOP:2.09 IN (53.09 MM) | Type of Adhesive： | |
MAXIMUM TEMPERATURE:225 F | (D) INNER DIAMETER,BOTTOM:2.09 IN (53.09 MM) | TYPE OF ENDCAP:PLATED STEEL | |
DIRECTION OF FLOW:OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:20 PSID | (E) LENGTH:9.80 IN (53.09 MM) (F) THREAD:NONE | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:SQ.IN. | |||
PLATING:ZINC PLATED | |||
OUTER JACKET:NONE | |||
CONFIGURATION:DOUBLE OPEN END | |||
