Product Details:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Months |
| Core Components: | HV Glassfiber, Glassfiber | Condition: | New |
| Power: | 800 | Weight: | 1 Kg |
| Dimension(L*W*H): | OEM | Warranty: | 1 Year |
| Filter Type: | External Oil Filter | Application: | Hydraulic Oil Filters |
| Material: | Important Glass Fiber | Function: | Clean Hydraulic Oil |
| MOQ: | 1pcs | Structure: | Cartridge Filter |
| OEM: | Available | Service Life: | 2000h |
| Performance: | Efficient Filtration |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 15.00 | (A) Outer Diameter, Top: 1.75IN | HANDLE:NONE | |
Beta Rating: B15=200 | (B) Outer Diameter, Bottom:1.75IN | Seal Material: VITON | |
Collapse Pressure Rating: 3000 PSI | (C) INNER DIAMETER, TOP:1.00IN | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:250 F | (D) Inner Diameter, Bottom:** | Type of Endcap: CORROSION RESISTANT STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:4.50IN | Center Tube: CORROSION RESISTANT STEEL | |
Get the quote by contacting us | Type of Media: 304 SS WIRE | ||
Filter Area: SQ.IN. | |||
Plating: ZINC PLATED | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
