Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Advertising Company |
|---|---|---|---|
| Weight (KG): | 0.2 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 0.2 | Gaskets - Material:: | NBR |
| Permitted Continuous Use Temperature:: | -25°C To +120°C | Filter Fineness [um(c)]:: | B4.5=1000 |
| Max. Differentia Pressure [bar]:: | 21 | Area Of Application:: | Hydraulics |
| Filter Medium:: | Glass Fiber |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:3.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:3.10 IN (78.74 MM) | Handle: NONE | |
Beta Rating:B3 = 200 | (B) OUTER DIAMETER, BOTTOM：3.10 IN (78.74 MM) | Seal Material:BUNA-N | |
Collapse Pressure Rating:150 PSID | (C) INNER DIAMETER, TOP:1.72 IN (43.69 MM) | Type of Adhesive:EPOXY | |
MAXIMUM TEMPERATURE:250 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) LENGTH:4.60 IN (0.00 MM) | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:270 SQ.IN. | |||
PLATING:ZINC PLATED | |||
OUTER JACKET:NONE - NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
