Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 1 | Application: | Hydraulics |
| Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:0.50 NOMINAL | (A) Outer Diameter, Top:7.63IN | Handle:NONE | |
Beta Rating:N/A | (B) Outer Diameter, Bottom:7.63IN | Seal Material:BUNA-N | |
Collapse Pressure Rating:75PSID | (C) Inner Diameter, Top:5.63IN | Type of Adhesive: EPOXY | |
Maximum Temperature:225F | (D) Inner Diameter, Bottom:5.63IN | Type of Endcap:PLATEDE STEEL | |
Direction of Flow: INTSIDE->IN | (E) Length:13.63IN | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media:FIBERGLASS | ||
Filter Area:936SQ.IN. | |||
Plating:ELECTROTIN PLATED | |||
Outer Jacket:YES - METAL | |||
Configuration:DOUBLE OPEN END | |||
