Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg: | 9 | Field Of Application: | Hydraulics |
| Filter Medium: | Glass Fiber | Seals-material: | NBR |
| Max. Will. Differential Pressure [bar: | 9 | Filter Fineness [μm(c): | 9 |
| Zul. Continuous Operating Temperature: | -25°C To +120°C |
|
Performance Data
|
Dimensional Specifications
|
Physical Specifications
|
|
|
MICRON RATING:3.00 ABSOLUTE
|
(A) OUTER DIAMETER, TOP:1.80 IN (45.72 MM)
|
HANDLE:NONE
|
|
|
BETA RATING:B3 = 200
|
(B) OUTER DIAMETER, BOTTOM:1.80 IN (45.72 MM)
|
Seal Material:BUNA-N
|
|
|
COLLAPSE PRESSURE RATING:3000 PSID
|
(C) INNER DIAMETER, TOP:1.00 IN (25.40 MM)
|
Type of Adhesive:EPOXY
|
|
|
MAXIMUM TEMPERATURE:250 F
|
(D) INNER DIAMETER,BOTTOM:
|
TYPE OF ENDCAP:PLATED STEEL
|
|
|
DIRECTION OF FLOW:OUTSIDE->IN
RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:50 PSID
|
(E) LENGTH:8.20 IN (0.00 MM)
(F) THREAD:NONE
|
CENTER TUBE:PLATED STEEL
|
|
|
Get the quote by contacting us
|
|
TYPE OF MEDIA:MICROGLASS
|
|
|
|
|
FILTER AREA:185 SQ.IN.
|
|
|
|
|
PLATING:ZINC PLATED
|
|
|
|
|
OUTER JACKET:NONE - NONE
|
|
|
|
|
CONFIGURATION:SINGLE OPEN END
|
|
